Capacity
Only mild steel laser cutting up to 25mm thickness and up to 3 metre length, subject to drawing and job feasibility.
Drawing-based MS job work
MS Laser Cutting Services in Mumbai
Clean, repeatable mild steel parts from DXF, DWG or PDF drawings. Regal Profile accepts MS jobs up to 25mm thickness and 3 metre plate length, with clear rate bands and practical delivery confirmation.
Material
Only mild steel (MS)
Thickness
Up to 25mm
Plate length
Up to 3 metre
Drawing files
DXF, DWG or PDF
Typical delivery
1-2 days
Minimum order
Rs. 5,000
- MSME / UdyamBusiness registration
- ISOCertificate available
- ExportIndian registration
- GST27AAPPK1319M1ZD
Recent Workshop Projects
MS plate and template work references
Review the part shape, edge, slots and repeat work before sending your own drawing and fitment notes.
MS Laser-Cut Machinery PartWork record
MS Laser-Cut Machinery Part from Regal Profile's Darukhana, Mazgaon workshop. Thickness: 1mm to 25mm. Material: IS 2062. Use: Machinery parts. Send drawing and quantity for quotation.
- Thickness:
- 1mm to 25mm
- Size:
- 200 x 300
- Material:
- IS 2062
- Application:
- Machinery parts
- Workshop:
- Darukhana, Mazgaon, Mumbai
MS Laser-Cut Machinery PartWork record
MS Laser-Cut Machinery Part from Regal Profile's Darukhana, Mazgaon workshop. Thickness: 1mm to 25mm. Material: IS 2062. Use: Machinery parts. Send drawing and quantity for quotation.
- Thickness:
- 1mm to 25mm
- Size:
- 300 x 100
- Material:
- IS 2062
- Application:
- Machinery parts
- Workshop:
- Darukhana, Mazgaon, Mumbai
MS Laser-Cut EOT Crane PartWork record
MS Laser-Cut EOT Crane Part from Regal Profile's Darukhana, Mazgaon workshop. Thickness: 1mm to 25mm. Material: IS 2062. Use: EOT crane components. Send drawing and quantity for quotation.
- Thickness:
- 1mm to 25mm
- Size:
- 130 x 70
- Material:
- IS 2062
- Application:
- EOT crane components
- Workshop:
- Darukhana, Mazgaon, Mumbai
MS Laser-Cut Machinery PartWork record
MS Laser-Cut Machinery Part from Regal Profile's Darukhana, Mazgaon workshop. Thickness: 1mm to 25mm. Material: IS 2062. Use: Machinery parts. Send drawing and quantity for quotation.
- Thickness:
- 1mm to 25mm
- Size:
- 80 x 100
- Material:
- IS 2062
- Application:
- Machinery parts
- Workshop:
- Darukhana, Mazgaon, Mumbai
MS Laser-Cut Automation ComponentWork record
MS Laser-Cut Automation Component from Regal Profile's Darukhana, Mazgaon workshop. Thickness: 1mm to 25mm. Material: IS 2062. Use: Automation equipment. Send drawing and quantity for quotation.
- Thickness:
- 1mm to 25mm
- Size:
- 300 x 150
- Material:
- IS 2062
- Application:
- Automation equipment
- Workshop:
- Darukhana, Mazgaon, Mumbai
MS Laser-Cut Machinery PartWork record
MS Laser-Cut Machinery Part from Regal Profile's Darukhana, Mazgaon workshop. Thickness: 1mm to 25mm. Material: IS 2062. Use: Machinery parts. Send drawing and quantity for quotation.
- Thickness:
- 1mm to 25mm
- Material:
- IS 2062
- Application:
- Machinery parts
- Workshop:
- Darukhana, Mazgaon, Mumbai
MS Laser-Cut EOT Crane PartWork record
MS Laser-Cut EOT Crane Part from Regal Profile's Darukhana, Mazgaon workshop. Thickness: 1mm to 25mm. Material: IS 2062. Use: EOT crane components. Send drawing and quantity for quotation.
- Thickness:
- 1mm to 25mm
- Size:
- 265 x 100
- Material:
- IS 2062
- Application:
- EOT crane components
- Workshop:
- Darukhana, Mazgaon, Mumbai
MS Laser-Cut Machinery Part - 25mmWork record
MS Laser-Cut Machinery Part - 25mm from Regal Profile's Darukhana, Mazgaon workshop. Thickness: 25mm. Material: IS 2062. Use: Machinery parts. Send drawing and quantity for quotation.
- Thickness:
- 25mm
- Size:
- 60 x 25
- Material:
- IS 2062
- Application:
- Machinery parts
- Workshop:
- Darukhana, Mazgaon, Mumbai
Workshop Videos
MS Laser Cutting workshop videos
Review cutting movement, plate handling and the finished part before sharing a similar requirement.
Verified Workshop Scope
What Regal Profile can confirm for MS Laser Cutting
Buyers should compare a supplier by the drawing details it checks, the work evidence it can show and the scope written into the quotation. Regal Profile has operated from Darukhana since 1995.
Document scope
State any material document, dimensional report or inspection requirement before quotation so it can be included or excluded clearly.
Workshop team
Operators and material-handling staff coordinate marking, cutting, checking and dispatch according to the accepted job scope.
Business identity
GSTIN 27AAPPK1319M1ZD, workshop address, phone and order details can be checked before payment or material dispatch.
Machine and process
DXF, DWG or PDF is checked for scale, closed profiles, holes, slots, nesting, quantity and required edge condition.
Inspection points
File revision, material thickness, overall dimensions, holes, slots, quantity and visible edge condition are checked.
Order input
Send DXF/DWG/PDF, MS thickness, sheet or part size, quantity, finish note and required delivery date.
Best-fit work
Parts we can review from your drawing
This process suits parts that need a clean outline, repeat sizing and clearly located holes or slots. Final acceptance follows a practical check of material, geometry and finish requirement.
Fabrication parts
Brackets, gussets, supports, covers and repeat components ready for the next fabrication stage.
Machine components
Guards, mounting plates, panels and drawing-based parts with clearly marked holes and slots.
Templates
Repeat marking, drilling and site-fit templates where the outer profile must remain consistent.
Batch work
Mixed parts or repeat quantities that can be reviewed together for nesting and material planning.
Structural fabrication
Gussets, cleats, mounting plates and connection parts prepared for welding or site assembly.
Maintenance work
Drawing-based replacement covers, brackets and plates where an old part or approved revision controls the shape.
Technical capacity
Confirmed workshop details
These are the current operating limits shared for quotation. Small holes, tight corners and critical fitment areas still need drawing review before the job is accepted.
| Accepted material | Only MS / mild steel sheet and plate work is accepted. |
|---|---|
| Thickness range | Jobs are checked from 1mm up to 25mm. Edge requirement and shape complexity are reviewed before acceptance. |
| Plate length | Length support is available up to 3 metre, subject to the drawing and material plan. |
| File input | DXF or DWG is preferred for clean cut paths. A dimensioned PDF can also be reviewed. |
| Critical dimensions | Mark holes, slots, mating faces and tolerance-sensitive areas instead of applying a tight tolerance everywhere. |
| Next operation | Mention bending, welding, machining, grinding, painting or coating so the part can be planned correctly. |
Outstation orders
MS laser-cut parts dispatched from Mumbai
Regal Profile's workshop is in Darukhana, Mumbai; these are dispatch routes, not branch-office locations. Confirmed drawing-based batches can be packed and reviewed for transport when the order value and part dimensions make outstation supply practical.Freight and delivery timing are confirmed after drawing, weight, packing and destination PIN code are checked.
Check industrial dispatch areasPune and Maharashtra
Bhosari, Chakan, Ranjangaon, Talegaon and other MIDC routes
Hyderabad and Telangana
Jeedimetla, Patancheru, Nacharam, Cherlapally and nearby industrial belts
Bengaluru and Karnataka
Peenya, Bommasandra, Jigani, Bidadi and major manufacturing clusters
Production-ready input
Prepare the CAD file before quotation
Clean geometry reduces revision calls, duplicate cutting paths and quantity mistakes. These checks matter more than simply naming the file DXF or DWG.
| Units and scale | Export the cut geometry at 1:1 scale and state millimetres clearly. Do not rely on an unlabelled screenshot. |
|---|---|
| Closed cut paths | Keep each profile closed and remove duplicate or overlapping lines that could create a double cut. |
| Part identity | Use a part number, revision and quantity for every shape, especially when several drawings share one plate. |
| Holes and slots | Show final hole diameter, slot width, center distance and any feature that controls fitment. |
| Critical tolerance | Mark only fitment-sensitive dimensions. Production tolerance is confirmed from thickness, geometry and the accepted drawing rather than one blanket figure. |
| Non-cut information | Keep bend lines, center lines, notes and reference geometry visibly separate from the actual cutting path. |
Quality and scope
Agree the expected result before cutting
Material condition, feature size and the next operation affect what a usable finished part looks like. Record these points in the accepted quotation instead of assuming them later.
| Drawing revision | The accepted quotation and cutting file should carry the same part number and revision. Revised geometry must be rechecked before production. |
|---|---|
| First piece and repeat batch | For fitment-sensitive work, identify the dimensions to check on the first piece before the remaining quantity is released. |
| Plate condition | Flatness, rust, mill scale, paint or coating can affect handling and edge expectations; mention supplied-material condition early. |
| Small features | Tiny holes, narrow slots and tight inside corners are reviewed against plate thickness before the file is accepted. |
| Cut edge | Edge condition varies with thickness, geometry and surface condition. Grinding, deburring or ready-to-paint finish must be quoted separately. |
| Material responsibility | Confirm whether MS material is supplied by the buyer or included in Regal Profile's quotation. |
| Inspection | State first-piece check, critical dimensions, quantity report or identification requirements before production. |
| Packing and dispatch | Mention part marking, bundle separation, pickup contact and delivery location when mixed parts are ordered together. |
Order flow
From CAD file to dispatch
Send the drawing
Share DXF, DWG or a dimensioned PDF with part names and quantity.
Confirm material
Mention MS thickness, grade if required, plate length and whether material is supplied by you or included in the enquiry.
Review the job
Cut length, holes, pierce points, nesting, edge requirement and delivery timing are checked before quotation.
Cut and coordinate
After approval, pickup or dispatch is coordinated from Darukhana, Mazgaon. Most regular work is planned within 1-2 days.
Drawing RFQ
Upload the MS laser drawing for workshop review
Send DXF, DWG, PDF or a clear part photo with thickness, quantity and delivery location. You can also leave your name and phone first and share the drawing with the workshop later.
- Mild steel only, up to 25mm after drawing review
- Maximum working length up to 3 metres
- Private drawing available only in the owner inbox
Current pricing
Indicative MS cutting rates
Rate per kilogram is a starting point. Cut length, number of pierces, file condition, quantity and urgency are reviewed before the final quotation is confirmed.
| 1mm to 10mm MS | Rs. 90/kg |
|---|---|
| 12mm to 25mm MS | Rs. 84/kg |
| Minimum order value | Rs. 5,000 |
Right process
Laser or profile cutting?
Laser is usually chosen for cleaner detail, smaller cutouts and repeat components within the stated MS range. Heavier plate or a different edge requirement may be better suited to profile cutting. The drawing decides the route, not the search term.
Compare Cutting MethodsPlanning estimate
Check the rate band by exact MS thickness
Enter the actual thickness and estimated job weight. The tool applies only the two published rate bands and sends uncertain sizes for manual checking instead of guessing.
Quick estimate
MS laser cutting rate estimator
Selected rate
Rs. 90/kg
Indicative order
9,000
Current published rate band: Rs. 90/kg.
Planning estimate only. Final quotation depends on drawing, cut length, pierce points, material, quantity, urgency and applicable taxes.
Send Estimate With DrawingBuyer resources
Prepare a better enquiry
Use the rate, capacity and drawing guides before sending a file. They answer the common questions that otherwise delay a quote.
Buyer questions
Frequently asked questions
What is the maximum MS thickness accepted?
Mild steel jobs are checked up to 25mm. Final suitability depends on the part geometry, small cutouts, edge expectation and drawing quality.
Which drawing format should I send?
DXF or DWG is preferred because the cut path can be reviewed directly. A PDF is also accepted when dimensions, holes and slots are clearly marked.
What are the current cutting rates?
The current indicative rate is Rs. 90 per kg for 1-10mm MS and Rs. 84 per kg for 12-25mm MS. The minimum order is Rs. 5,000. Final price follows drawing review.
How quickly can a confirmed job be completed?
Regular confirmed work is usually planned in 1-2 days. Urgent work is accepted only after checking the file, material and current workshop schedule.
Do you cut stainless steel or aluminium?
No. This service is currently focused only on mild steel so buyers receive a clear material-specific quotation.
Can repeat production parts be nested together?
Yes. Send every part file and quantity together so plate utilization, repeat cutting and delivery can be planned as one batch.
Do you promise one fixed tolerance for every laser-cut part?
No blanket tolerance is applied to every job. Critical dimensions are reviewed from material thickness, feature size, geometry, edge expectation and the approved drawing before acceptance.
Should DXF files be supplied at full scale?
Yes. Send 1:1 geometry with units stated, closed cut paths, no duplicate lines, and separate non-cut reference or bend information.
Can deburring, grinding or a ready-to-paint edge be included?
Mention the required edge condition before quotation. Cutting and secondary finishing are treated as separate scope items and confirmed job-wise.
Can buyer-supplied MS material be reviewed?
State whether material will be supplied by the buyer or should be included in the quotation. Plate grade, thickness, size and surface condition are checked before acceptance.
What happens when the plate is unsuitable for laser?
The workshop will explain the issue and may suggest profile cutting for heavier plate or shapes where that route is more practical.
Where is the workshop located?
Regal Profile operates from Reti Bunder Road, Darukhana, Mazgaon, Mumbai and coordinates pickup or dispatch for nearby industrial areas.
Can MS laser-cut parts be dispatched outside Mumbai?
Yes. Accepted batch jobs can be reviewed for dispatch to Pune and other Maharashtra MIDCs, Hyderabad and Telangana, and Bengaluru and Karnataka. Freight, packing and delivery time are confirmed from job weight and destination PIN code.
Recent Work
Recent MS laser cutting work
Recent jobs with workshop photos, work dates and the available material or size details.
MS Laser Cutting5
MS Laser Cutting1
MS Laser Cutting14
Darukhana, Mazgaon
Send the file for a practical check
Regal Profile has operated from Mumbai's steel market since 1995. Share the drawing and job details before arranging material movement or workshop pickup. GSTIN: 27AAPPK1319M1ZD.
